Development and manufacture of cutting mills and size reduction machines for the processing of plastic residues and plastic waste.
Hellweg Maschinenbau GmbH & Co. KG
Vennstrasse 10, D-52159 RoetgenNew on Amplifa
About Hellweg Maschinenbau
Hellweg Maschinenbau GmbH & Co. KG, based in Roetgen (North Rhine-Westphalia), is a family business founded in 1985 by Bernd Hellweg that specializes in the development and manufacture of size reduction machines – in particular cutting mills – for the plastics industry. The standardized product range includes laboratory mills, beside-the-press mills, toothed roller mills, central mills, lump mills, punched-grid mills and edge strip mills in various sizes, complemented by film cutters, guillotines, pipe cutters, dedusting systems, mobile extraction systems and complete fully automatic recycling systems. The cutting mills operate according to the shear-oblique-cut principle; the rotors are machined from a single piece of material and have no weld seams. Thermoplastics such as ABS, PA, PA66GF, PE, PP, PBT, PC, PS, POM as well as TPE, TPU and more are granulated. The products are manufactured in-house and subjected to extensive test runs before delivery. In addition, the company offers customer-specific special solutions, grinding trials in its own in-house laboratory, spare parts management and the digital Smart Control control system for energy-saving operation. Sales are handled worldwide through representatives in 17 countries.
- Site
- Roetgen
- Processes
- Plastic granulation with cutting mills (shear-oblique-cut principle), Edge strip disposal, processing and recycling, Film cutting (converting of film webs, edge trimming), Volume reduction of edge strips (pipe cutter/in-pipe cutter), Pre-granulation of edge strips with guillotines (sheet thicknesses up to 18 mm), CD/DVD recycling - low-dust granulation of sprues and blanks made of polycarbonate (MRS/BRS,, Dedusting of regrind (separation of dust/granulate, mobile extraction), Granulation with toothed roller mills (Slotter, screenless, low dust)
- Materials
- ABS, ASA, EPS, EPDM, EVA, CFRP, GF (glass fibre), PA
- Certificates
- In-house manufacturing with QA system covering the entire production chain, Test runs of all products before delivery, In-house laboratory for grinding trials, CE marking of the machines
- Founded
- 1985
- Industries
- Plastics industry, Plastics recycling, Blow moulding industry (PET preforms, film), Injection moulding / optical media (CD/DVD), Food industry, Paper industry
- 01
Engineering (2D/3D CAD)
- 02
CNC manufacturing (machining)
- 03
Assembly
- 04
Quality assurance with test runs
- 05
Worldwide sales
Materials & Processes
Cutting mills (laboratory mills, beside-the-press mills, central mills, lump
Size reduction of thermoplastic production waste according to the shear-oblique-cut principle into low-dust regrind.
Toothed roller mills (Slotter)
Slow-running, screenless mills for gentle, low-dust size reduction of sprues and reject parts.
Dedusting systems & extraction systems
Separation of dust and granulate to produce dust-free regrind.
Edge strip granulation (RS, RC, LSZ, RST, R 200/20)
Processing and volume reduction of edge strips from film and sheet production.
Film cutters (Form A, E, D, D-W50, F)
Slitting and converting of tubular film in blown film lines.
MRS & BRS (CD/DVD recycling)
Low-dust granulation of sprues and blanks made of polycarbonate in a closed loop.
GRANUmaster Smart Control / Smart Control+
Digital control system with real-time monitoring of power consumption, speed and temperatures; eco mode reduces energy consumption by up to 40 percent.
Locations
Roetgen
DEHeadquarters, development, manufacturing, assembly, laboratory
- Materials
- Thermoplastics (ABS, PA, PE, PP, PC, PET, TPE among others)
- CNC machining machines (since 1990)
- Production halls
- second assembly hall (2020)
- in-house laboratory
- office building (2023)
Components
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Plastic granulation with cutting mills (shear-oblique-cut principle)Machining | – | – | – | – | – |
| Edge strip disposal, processing and recyclingPlastics | – | – | – | – | Thin films (e.g. HD-PE, LD-PE) |
| Film cutting (converting of film webs, edge trimming)Plastics | – | – | – | – | HD-PE, LD-PE, Tubular film |
| Volume reduction of edge strips (pipe cutter/in-pipe cutter)Plastics | – | – | – | – | Thin films |
| Pre-granulation of edge strips with guillotines (sheet thicknesses up to 18 mm)Plastics | – | – | – | – | Plastic sheets |
| CD/DVD recycling - low-dust granulation of sprues and blanks made of polycarbonate (MRS/BRS,Plastics | – | – | – | – | Polycarbonate (PC) |
| Dedusting of regrind (separation of dust/granulate, mobile extraction)Surface treatment | – | – | – | – | Plastic regrind |
| Granulation with toothed roller mills (Slotter, screenless, low dust)Plastics | – | – | – | – | Plastics (sprues, reject parts) |
| Wet grinding (wet cutting mills Series 600 W with forced feeding)Plastics | – | – | – | – | Plastics |
| Grinding of PET preforms and PET bottles (blow moulding industry)Plastics | – | – | – | – | PET |
| In-house manufacturing/contract manufacturing with CNC technology (machining, engineering)Engineering | – | – | – | – | Steel |
| Assembly of granulators in own production with QA system and test runsAssembly | – | – | – | – | – |
| Testing: test runs of all products before delivery, in-house laboratory for grinding trialsTesting | – | – | – | – | – |
25 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| Laboratory mill | Hellweg Maschinenbau Series 80 | – | Working width 50 mm, rotor diameter 80 mm | – | Roetgen |
| Laboratory mill/mini beside-the-press mill | Hellweg Maschinenbau Series 100 | – | Working width 100 mm, rotor diameter 100 mm | – | Roetgen |
| Beside-the-press mill | Hellweg Maschinenbau Series 150 | – | Working width 120/230/340 mm, rotor diameter 150 mm | – | Roetgen |
| Beside-the-press mill (PET preform cutting mill) | Hellweg Maschinenbau Series 200 | – | Working width 240/320/410/650/1,050 mm, rotor diameter 200 mm | – | Roetgen |
| Roller mill (toothed roller mill) | Hellweg Maschinenbau Series 250 Slotter | – | Working width 150/250/330/410 mm, rotor diameter 105 mm | – | Roetgen |
| Central mill | Hellweg Maschinenbau Series 180 | – | Working width 240 mm, rotor diameter 180 mm | – | Roetgen |
| Central mill | Hellweg Maschinenbau Series 260 | – | Working width 410/650 mm, rotor diameter 260 mm | – | Roetgen |
| Central mill | Hellweg Maschinenbau Series 300 (incl. 300 BR) | – | Working width 300/450/600/900/1,200 mm, rotor diameter 300 mm | – | Roetgen |
| Central mill | Hellweg Maschinenbau Series 450 | – | Working width 600/1,200 mm, rotor diameter 450 mm | – | Roetgen |
| Large cutting mill | Hellweg Maschinenbau Series 600 / MG 1500/600 | – | – | – | Roetgen |
| Wet cutting mill | Hellweg Maschinenbau Series 600 W | – | – | – | Roetgen |
| Lump mill | Hellweg Maschinenbau Series 260 BR (MG 240/260 BR) / MDSG 1000/600 BR | – | – | – | Roetgen |
| Punched-grid mill (thermoform infeed mill) | Hellweg Maschinenbau Series RST Thermoform | – | – | – | Roetgen |
| Infeed device for film edge strips | Hellweg Maschinenbau Series RS | – | – | – | Roetgen |
| Edge strip granulator | Hellweg Maschinenbau Series LSZ | – | – | – | Roetgen |
| Pipe cutter (edge strip volume reduction) | Hellweg Maschinenbau Series RC | – | – | – | Roetgen |
| Guillotine/chopper (edge trimming system) | Hellweg Maschinenbau Series R 200/20 | – | Sheet thicknesses up to 18 mm | – | Roetgen |
| Film cutter | Hellweg Maschinenbau Form A / Form E / Form D / Form D-W50 / Form F | – | – | – | Roetgen |
| Pipe cutter (in-pipe cutter) | Hellweg Maschinenbau | – | – | – | Roetgen |
| CD/DVD sprue mill (material recycling system) | Hellweg Maschinenbau MRS | – | Working width 50 mm, rotor diameter 80 mm | – | Roetgen |
| CD/DVD blank disc mill | Hellweg Maschinenbau BRS (Series 260) | – | Working width 410 mm, rotor diameter 260 mm | – | Roetgen |
| Dedusting system | Hellweg Maschinenbau | – | Extraction capacity 50-1,200 kg/h, dimensions approx. 2,500 x 1,000 x 3,000 mm | – | Roetgen |
| Mobile extraction system | Hellweg Maschinenbau | – | Extraction capacity up to 300 kg/h, dimensions approx. 800 x 800 x 2,000 mm | – | Roetgen |
| CNC machining machine (first acquired in 1990, machining production) | – | – | – | 1990 | Roetgen |
| Control system for cutting mills | Hellweg Maschinenbau GRANUmaster Smart Control / Smart Control+ | – | – | 2018 | Roetgen |
Additional services
Reference customers
Quality
Hellweg Maschinenbau manufactures in its own production and can therefore guarantee consistent quality. A specially developed quality assurance system monitors the entire production chain; before delivery, all products are subjected to extensive test runs.
| Evidence | Roetgen |
|---|---|
| In-house manufacturing with QA system covering the entire production chain | |
| Test runs of all products before delivery | |
| In-house laboratory for grinding trials | |
| CE marking of the machines |
