About Maxitrol
Maxitrol Company manufactures gas pressure regulators, modulating valves, gas control and shutoff valves, and filtration systems for the gas industry. The product range includes the RV, 325, R/RS, RZ, 220 and SR regulator series, the Selectra and EXA modulating valves, SENTRY excess-flow and thermal cut-off valves, Ball Valves, GV, CV and GW systems, and the GF1000 and HF2000 filters. In production, cast housings (top castings) of the RV52, RV53, 325 and R400 series are machined on a purpose-built special machine (M92): each housing is drilled/reamed and qualified before the vent spindles are threaded. The units are then assembled from the machined cast components. Production sites are Thale (Germany) and Colon (USA). Customers come from the gas industry.
- Site
- Thale
- Processes
- Reaming (drilling/reaming) of cast housings (top castings), Threading of vent spindles/vent stacks, Machining of top castings (RV52, RV53, 325, R400 regulator housings), Quality inspection/qualification of the castings after machining, Assembly/production of gas pressure regulators, gas control and shutoff valves (RV, 325, R/RS, RZ,
- Materials
- Cast castings (regulator housings, e.g. RV52, RV53, 325, R400), Cast castings, Reaming (drilling/reaming), Threading, Assembly
- Industries
- Gas industry
- 01
Cast housing production
- 02
Machining of the top castings (reaming)
- 03
Qualification of the castings
- 04
Threading of the vent spindles
- 05
Assembly of the gas pressure regulators and valves
- 06
Quality inspection
Materials & Processes
Cast castings
Regulator housings (top castings) of the RV52, RV53, 325 and R400 series, produced and machined for in-house unit production.
Reaming (drilling/reaming)
Machining of the cast housings on the M92 special machine, followed by qualification of each casting.
Threading
Used to manufacture the vent spindles and vent stacks.
Assembly
Final assembly of gas pressure regulators, modulating valves and shutoff valves from the machined components.
Sites
Thale
DEProduction (production hall)
- Materials
- Cast castings
Colon
DEProduction site (USA) – machining of regulator cast housings
- Materials
- Cast castings
- M92 special machining machine for regulator castings
Products & Components
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Reaming (drilling/reaming) of cast housings (top castings)Machining | – | – | – | – | – |
| Threading of vent spindles/vent stacksMachining | – | – | – | – | – |
| Machining of top castings (RV52, RV53, 325, R400 regulator housings)Machining | – | – | – | – | Castings (housing castings) |
| Quality inspection/qualification of the castings after machiningInspection | – | – | – | – | – |
| Assembly/production of gas pressure regulators, gas control and shutoff valves (RV, 325, R/RS, RZ,Assembly | – | – | – | – | – |
1 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| Special machining machine for regulator castings | Maxitrol M92 | 1 | – | – | Colon (production site) |
History
Installation of the original Maxitrol logo sign from the Senden (Germany) facility at the production hall in Thale
Commissioning of the M92 special machine in Colon for machining the RV52, RV53, 325 and R400 top castings
