Modell und Werkzeugbau GmbH in Torgelow is a service provider for machining, pattern and mould making, toolmaking and prototype construction. In contract manufacturing, components are produced by 3-axis CNC milling up to 1800 x 1000 mm, by 3+2-axis and 5-axis simultaneous milling up to a swing circle of Ø1040 mm, and by CNC turning up to Ø820 x 2000 mm; cast parts and welded constructions are also machined, while grinding and EDM are carried out in cooperation with contracting partners. In pattern and mould making, the company produces casting moulds for mineral casting, laminating moulds, foaming moulds, dies for the lost-wax process, as well as machine-moulding, hand-moulding and prototype pattern equipment up to 1600 x 1200 mm in all quality grades, including core boxes for core shooting machines and hot-box core boxes. In addition, the company manufactures tools and fixtures such as breaking, cutting, punching and deburring tools, measuring and inspection fixtures, as well as welding, bending and drilling fixtures. A quality management system certified to ISO 9001:2015 accompanies production.
- Site
- Torgelow
- Processes
- 3-axis CNC milling of components, 3+2-axis and 5-axis simultaneous milling, CNC turning, Machining of cast parts, Machining of welded constructions, Grinding (in cooperation with contracting partners), EDM (in cooperation with contracting partners), Casting moulds for mineral casting
- Materials
- Mineral casting, Metal, Plastic, Wood, Casting (cast parts), 3-axis CNC milling, 3+2-axis and 5-axis simultaneous milling, CNC turning
- Certificates
- ISO 9001:2015
- Industries
- Foundry industry, Toolmaking, Mechanical engineering, Plastics processing, Foundry / toolmaking (generic from Wikipedia, not company-specific)
- 01
Design / receipt of CAD data
- 02
CNC milling (3-axis, 3+2-axis, 5-axis simultaneous)
- 03
CNC turning
- 04
Machining of cast parts and welded constructions
- 05
Grinding / EDM (in cooperation)
- 06
Assembly / inspection
Materials and processes
3-axis CNC milling
Machining of components up to max. 1800 x 1000 mm in metal, plastic and wood.
3+2-axis and 5-axis simultaneous milling
Contour-accurate machining up to max. swing circle Ø1040 mm.
CNC turning
Rotationally symmetrical parts up to max. Ø820 x 2000 mm.
Casting moulds for mineral casting
Moulds for mineral casting processing in the foundry.
Laminating and foaming moulds
Moulds for lightweight construction and foaming processes.
Dies for the lost-wax process
Dies for investment casting applications.
Machine-moulding, hand-moulding and prototype pattern equipment
Pattern equipment in all quality grades up to max. 1600 x 1200 mm.
Core boxes incl. hot box
Core boxes for core shooting machines incl. pneumatic and hydraulic systems, sensor technology and electric heating system.
Tool and fixture making
Breaking, cutting, punching and deburring tools as well as measuring, welding, bending and drilling fixtures.
Prototype construction
Milled prototype components in metal, plastic and wood as well as casting prototypes in all common materials.
Locations
Torgelow
DEHeadquarters and production
- Lot size
- Prototype, one-off production, small to large series
- Materials
- Metal, plastic, wood, cast parts
- 3-axis CNC milling machines (up to 1800 x 1000 mm)
- 3+2-axis and 5-axis simultaneous milling machines (up to swing circle Ø1040 mm)
- CNC lathes (up to Ø820 x 2000 mm)
- Conventional manufacturing
Components
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| 3-axis CNC milling of componentsMachining | – | 1800 mm × 1000 mm | – | – | Metal, Plastic, Wood |
| 3+2-axis and 5-axis simultaneous millingMachining | – | – | – | – | – |
| CNC turningMachining | – | 2000 mm | Ø820 mm | – | – |
| Machining of cast partsMachining | – | – | – | – | Casting |
| Machining of welded constructionsMachining | – | – | – | – | Steel |
| Grinding (in cooperation with contracting partners)Machining | – | – | – | – | – |
| EDM (in cooperation with contracting partners)Machining | – | – | – | – | – |
| Casting moulds for mineral castingCasting | – | 1600 mm × 1200 mm | – | – | Mineral casting |
| Laminating mouldsCasting | – | – | – | – | Plastic |
| Foaming mouldsCasting | – | – | – | – | Plastic |
| Dies for the lost-wax processCasting | – | – | – | – | – |
| Machine-moulding pattern equipment in all quality gradesCasting | – | 1600 mm × 1200 mm | – | – | – |
| Hand-moulding pattern equipment in all quality gradesCasting | – | – | – | – | – |
| Prototype pattern equipment (pattern plates and core boxes)Casting | – | – | – | – | – |
| Core boxes for core shooting machines incl. pneumatic/hydraulic system and sensor technologyCasting | – | – | – | – | – |
| Hot box core boxes including electric heating systemCasting | – | – | – | – | – |
| Breaking and cutting toolsToolmaking | – | – | – | – | – |
| Deburring tools, punching toolsToolmaking | – | – | – | – | – |
| Measuring and inspection fixturesInspection | – | – | – | – | – |
| Welding, bending and drilling fixturesToolmaking | – | – | – | – | – |
| Tools for the manufacture of insulation systemsToolmaking | – | – | – | – | – |
| Transport and assembly fixturesAssembly | – | – | – | – | – |
| Prototype tools (e.g. core tools)Toolmaking | – | – | – | – | – |
| Milled prototype componentsMachining | – | – | – | – | Metal, Plastic, Wood |
| Casting prototypesCasting | – | – | – | – | all common materials |
| Conventional (non-CNC) manufacturingMachining | – | – | – | – | – |
3 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| 3-axis CNC milling machine | – | – | Components up to max. 1800 x 1000 mm | – | – |
| 5-axis simultaneous milling machine / 3+2-axis milling machine | – | – | up to max. swing circle Ø1040 mm | – | – |
| CNC lathe | – | – | up to max. Ø820 x 2000 mm | – | – |
Additional services
Quality
A quality management system certified to ISO 9001:2015 guarantees consistently high product quality; measuring and inspection fixtures are also manufactured as products in the company's own toolmaking operation.
