Pattern and mould making for foundries: patterns made of wood, foam, synthetic resin, plastic and styrofoam to DIN EN 12890.
Modellbau Peter Helm
Duisburg-Aldenrade (DE) · Poland (MB HELM Piotr Helm)New on Amplifa
About Modellbau Peter Helm
Modellbau Peter Helm is a sole proprietorship for pattern and mould making founded by Peter Helm in 2000, based in Duisburg-Aldenrade. At the Duisburg site, patterns made of wood, foam, synthetic resin, plastic and styrofoam are produced, built and maintained. The service spectrum ranges from prototype production to pattern moulds and hand moulding patterns through to series tooling. The company supplies patterns for the production of sand moulds and sand cores to DIN EN 12890 and manufactures castings in cooperation with partner companies. Modern CAD/CAM techniques are used for moulding in production; the offering also includes design, mould drawing as well as planning and on-site consulting. The patterns are used, among other things, in the foundry and casting industry, drive technology, mining technology, gearbox construction, hydraulic and wear-resistant castings, engine construction, pump construction, marine propulsion and wind power. Since 2021, the company has also been active on the Polish market as MB HELM Piotr Helm, as the successor to Joszko Modele.
- Site
- Duisburg
- Processes
- Pattern and mould making (produce, build and maintain patterns), CAD/CAM moulding in production, Casting production (with partners), Prototype production, Pattern moulds, Hand moulding patterns, Series tooling, Patterns for the production of sand moulds and sand cores (DIN EN 12890)
- Materials
- Wood, Foam, Synthetic resin, Plastic, Styrofoam, Plywood (sklejka)
- Certificates
- DIN EN 12890 (patterns for sand moulds and sand cores)
- Founded
- 2000
- Industries
- Foundry/casting industry, Drive technology, Mining technology, Gearbox construction, Hydraulic castings, Engine construction
- 01
On-site consulting and planning
- 02
Analysis of drawing, sketch or 3D data
- 03
Design and mould drawing
- 04
CAD/CAM moulding
- 05
Pattern and mould making
- 06
Repair of patterns
- 07
Casting production with partners
Materials and Processes
Wood
Traditional material for hand moulding patterns and wooden permanent patterns.
Plywood (sklejka)
Material for casting patterns in pattern and mould making.
Foam
Material for patterns and moulds with low requirements on surface hardness.
Synthetic resin
Material for durable moulds and patterns in the casting sector.
Plastic
Material for pattern moulds and plastic moulds.
Styrofoam
Material for styrofoam patterns, especially for casting patterns.
Sites
Duisburg
DEProduction, pattern and mould making
- Materials
- Wood, foam, synthetic resin, plastic, styrofoam
- CAD/CAM technology
Patterns and Components
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Pattern and mould making (produce, build and maintain patterns)Engineering | – | – | – | – | Wood, Foam, Synthetic rubber/resin, Plastic |
| CAD/CAM moulding in productionEngineering | – | – | – | – | – |
| Casting production (with partners)Casting | – | – | – | – | – |
| Prototype productionEngineering | – | – | – | – | – |
| Pattern mouldsEngineering | – | – | – | – | – |
| Hand moulding patternsCasting | – | – | – | – | Wood, Foam, Synthetic resin, Plastic |
| Series toolingEngineering | – | – | – | – | – |
| Patterns for the production of sand moulds and sand cores (DIN EN 12890)Casting | – | – | – | – | – |
| Wooden permanent patternsCasting | – | – | – | – | Wood |
| Plastic / plastic resin mouldsPlastics | – | – | – | – | Plastic, Plastic resin |
| Styrofoam patternsCasting | – | – | – | – | Styrofoam |
| Hydraulic castings / wear-resistant castings (patterns)Casting | – | – | – | – | – |
| Planning, consulting and drawing of custom mouldsEngineering | – | – | – | – | – |
| Production of odlewnicze patterns (casting patterns)Casting | – | – | – | – | drewno (wood), sklejka (plywood), pianka (foam), żywica syntetyczna (synthetic resin), styropian (styrofoam) |
Additional services
Quality
Patterns are manufactured to DIN EN 12890 for sand moulds and sand cores; materials and quality grades determine the quality. Certifications are not documented.
| Evidence | Duisburg |
|---|---|
| DIN EN 12890 (patterns for sand moulds and sand cores) |
Company History
- 2000
Company founded by Peter Helm, start of activities on the German pattern-making market
- 2005
Peter Helm listed as Company Owner of Modellbau Peter Helm on LinkedIn
- 2021
Activity on the Polish market as MB HELM Piotr Helm, successor to Joszko Modele
