Sheet metal processing and welded assemblies from single parts to series assemblies, certified for rail vehicle construction.
PZ Blechtechnik GmbH
AachenNew on Amplifa
About us
PZ Blechtechnik GmbH is a sheet metal fabricator from Aachen offering complex sheet metal processing from single parts to large assemblies in series. The range of services includes consulting, 3D design and development, laser cutting, bending, punching, shearing, roll bending, welding, riveting, machining, grinding, deburring, as well as surface finishing and assembly, including sound insulation technology. Products manufactured include laser-cut blanks, laser-bent parts, welded assemblies, tube frames, containers and complete assemblies. Materials used are steel, stainless steel and aluminium. The company is certified by TÜV Rheinland as a welding operation for rail vehicle construction in accordance with EN 15085-2 (classification level CL1) and as a certified welding shop in accordance with EN ISO 3834-2. Customers come from rail vehicle construction, industry and the trades. Production takes place at the headquarters on Liebigstrasse in Aachen on a modern machine fleet with its own nitrogen generation.
- Site
- Aachen
- Processes
- Laser cutting (sheet metal), Bending of sheet metal, Welding (welding technology), Welding in rail vehicle construction to EN 15085-2 (process 135 MAG, material group 1.2, t=1.4–24, Grinding, Riveting, Machining, Surface finishing (surface treatment)
- Materials
- Steel, Stainless steel, Aluminium
- Certificates
- EN 15085-2 (rail vehicle construction, classification level CL1), EN ISO 3834-2 (certified welding shop), EN 15085-2 CL1, EN ISO 3834-2
- Industries
- Rail vehicle construction, Industry, Trades
- 01
Consulting
- 02
Design and development
- 03
Laser cutting
- 04
Bending/Punching/Roll bending
- 05
Welding
- 06
Grinding/Deburring
- 07
Surface finishing
- 08
Assembly
Materials & Processes
Steel
Base material for laser-cut blanks, bent parts and welded assemblies.
Stainless steel
For corrosion-exposed components and welded assemblies.
Aluminium
Lightweight material for sheet metal parts and welded constructions.
Sites
Aachen
DEHeadquarters / Production
- Lot size
- Single parts to series assemblies
- Materials
- Steel, stainless steel, aluminium
- Mazak Optiplex 3015 fiber 4 kW laser cutting machine
- SafanDarley H-Brake 110-1600 Premium press brake
- EHT ProfiPress 230/4050 press brake
- LVD CS sheet shearing machine
- Boschert EL500 punching machine
- 3-roll roll bending machine
- Deburring machine
- Nitrogen generation
Components
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Laser cutting (sheet metal)Machining | – | – | – | – | Sheet metal, Steel, Stainless steel, Aluminium |
| Bending of sheet metalForming | – | – | – | – | Sheet metal, Steel, Stainless steel, Aluminium |
| Welding (welding technology)Joining | – | – | – | – | Steel, Stainless steel, Aluminium |
| Welding in rail vehicle construction to EN 15085-2 (process 135 MAG, material group 1.2, t=1.4–24Joining | – | 500 mm (D) | – | – | Steel, Stainless steel, Aluminium |
| GrindingSurface | – | – | – | – | – |
| RivetingJoining | – | – | – | – | Sheet metal |
| MachiningMachining | – | – | – | – | – |
| Surface finishing (surface treatment)Surface | – | – | – | – | – |
| AssemblyAssembly | – | – | – | – | – |
| 3D design and developmentEngineering | – | – | – | – | – |
| PunchingForming | – | – | – | – | Sheet metal |
| Sheet shearing (cutting)Machining | – | – | – | – | Sheet metal |
| Roll bending (3-roll)Forming | – | – | – | – | Sheet metal |
| DeburringSurface | – | – | – | – | Sheet metal |
| Manufacture of tube frames, containers, welded assemblies, complete assembliesJoining | – | – | – | – | – |
8 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| Laser cutting machine | Mazak Optiplex 3015 fiber 4KW | 1 | – | – | Aachen |
| Press brake | SafanDarley H-Brake 110-1600 Premium | 1 | – | – | Aachen |
| Press brake | EHT ProfiPress 230/4050 | 1 | – | – | Aachen |
| Sheet shearing machine | LVD CS | 1 | – | – | Aachen |
| Punching machine | Boschert EL500 | 1 | – | – | Aachen |
| 3-roll roll bending machine | – | 1 | – | – | Aachen |
| Deburring machine | – | 1 | – | – | Aachen |
| Nitrogen generation | – | – | – | – | Aachen |
Additional services
Quality & Certification
Quality assurance is based on the certified welding processes in accordance with EN 15085-2 (CL1) and EN ISO 3834-2 with qualified welding supervisors (IWE/EWS).
| Evidence | Aachen |
|---|---|
| EN 15085-2 CL1 | |
| EN ISO 3834-2 |
History
- 2021
First issuance of the EN ISO 3834-2 certificate by TÜV Rheinland
- 2023
Renewal of the EN 15085-2 CL1 certification (valid until 18.02.2026)
